Gasoline Water Pump

Specifications •Voltage:220/50 •No Load Speed:2800 • Power:4200 •Pressure:7-10 •Flow :60

Specifications Voltage:220/50 •No Load Speed:2800 •Power:4200 •Pressure:7-10 •Flow :30

Suction&Discharge port diameter:25mm,1" Max.flow:100L/min Max.head lift:16m Max.suction head:7m 2.5HP gasoline engine Displacement::105cc Fule tank:1.2L Starting system:Recoil Packed by carton box

Suction&Discharge port diameter:50mm,2" Max.flow:550L/min Max.head lift:28m Max.suction head:8m 7.0HP gasoline engine Displacement:208cc Fuel tank:3.6L

Suction&Discharge port diameter:80mm,3" Max.flow:1000L/min Max.head lift:32m Max.suction head:8m 7.0HP gasoline engine Displacement:208cc Fuel tank:3.6L

Suction&Discharge port diameter:100mm,4" Max.flow:1500L/min Max.head lift:30m Max.suction head:8m 9.0HP gasoline engine Displacement:270cc Fuel tank:6.0L

Gasoline high pressure water pump Suction port diameter : 50mm,2" Discharge port diameter:50mm,2"/40mm,1.5"/40mm,1.5" Max.flow:300L/min Max.head lift:75/80/80m Max.suction head:7m 7.5HP gasoline engine Displacement:212cc

Power   Single-cylinder/4-stroke/air cooled/ Displacement  208cc Rated power    4000W Rated speed 3600r/min Input/Output diameter  80(3’’)mm Pumping Head  19m Flow 30m3/h Self-priming height 5m Self-priming time <_ 160s Net weight 30kg

Power   Single-cylinder/4-stroke/air cooled/ Displacement  196cc Rated power    3200W Rated speed 3600r/min Input/Output diameter  50(2’’)mm Pumping Head  20m Flow 20m3/h Self-priming height 5m Self-priming time <_ 140s Net weight 25kg

Suction&Discharge port diameter:75mm,3" Max.flow:1000L/min Max.head lift:32m Max.suction head:8m 7.0HP Gasoline engine Displacement:208cc Fuel tank:3.6L

Suction&Discharge port diameter:100mm,4" Max.flow:1500L/min Max.head lift:30m Max.suction head:8m 9.0HP Gasoline engine Displacement:270cc Fuel tank:6.0L

Engine Type 2-Stroke, Air-Cooled, Single Cylinder Displacement 42.7CC Suction Dia 25mm(1") Discharge Dia 25mm(1") Total Height 30M Max. Suction Height 8M
